EVIL ENERGY 4/6/8/10/12AN Flare to 4/6/8/10/12AN ORB Male 45/90 Degree Full Flow Fitting Adapter Aluminum Black

---!@!start!@!---Specifications---!@!end!@!---

Product Type	AN Flare to AN ORB Male Adapter Fitting
Available Sizes	4AN / 6AN / 8AN / 10AN / 12AN
AN Thread Sizes	4AN 7/16-20 UNF 6AN 9/16-18 UNF 8AN 3/4-16 UNF 10AN 7/8-14 UNF 12AN 1-1/16-12 UNF
Material	6061-T6 Aluminum
Surface Finish	Black Anodized
Working Pressure	Up to 1500 PSI
Operating Temperature	-65°F to 252°F
O-ring Temperature Range	-4°F to 392°F

---!@!start!@!---Description---!@!end!@!---

The EVIL ENERGY AN flare to AN ORB male adapter fitting is designed to connect a 37 degree AN flare hose end to an ORB port on fuel rails, fuel pumps, regulators, filters, oil coolers, fuel cells, and other performance plumbing components.

AN to ORB fittings For more routing options, browse our AN fittings and to match fuel rails, regulators, filters, and oil cooler ports.

Constructed from lightweight 6061 T6 aluminum with a corrosion resistant black anodized finish, this adapter is ideal for fuel rails, fuel pumps, regulators, filters, and oil coolers in street, performance, and racing applications.

If you are building a complete fuel delivery layout, pair this adapter with compatible fuel lines and matching hose end fittings based on your AN size and routing angle.
